xerpi

has managed to get the PS4’s Dualshock 4 control pad running on the Wii, here is a quote from his artcle on the forum:

I’ve spent a few days trying to get a connection between the Wii and a Dualshock 4. In order to get it working, I had to do some “reverse engineering” to the libogc’s Bluetooth stack and I finally found what was happening: the Bluetooth protocol authentication part of the libogc’s bluetooth stack was missing. I’ve already submitted a patch to the official libogc repository.

Well, after getting the “authentication” working, I started implementing the specific DS4 bluetooth protocol (thanks to here and here).

The Dualshock4 need to be paired through USB before establishing a Bluetooth connection, so I’ve crafted a program called ds4pair_wii that makes this, it pairs the DS4 to the Wii’s Bluetooth address. ds4pair_wii also writes to the SD a file called ds4wiibt_config, which has a list of each MAC of all the paired DS4 controllers.

After pairing, the connection can be established, once you press the PS button, the Dualshock 4 will try to connect to its paired MAC. Before this, the Wii has to be listening (aka waiting) for the DS4 controller to be turned on. After this, connections is established.

Steps:

  1. Run ds4pair_wii with the DS4 connected over USB, it’ll create a config file to the SD
  2. Run ds4wiibt (it’ll load the config file), turn on the DS4 (press PS button)

Compiled apps: https://www.mediafire.com/?1ld710qi1whk55i
ds4wiibt source code: https://github.com/xerpi/ds4wiibt
ds4pair_wii source code : https://github.com/xerpi/ds4pair_wii

Enjoy!
